HAX 4000
Front Panel Shows:
- SMART DIGITAL LCD DISPLAY which shows temperature, operating mode.
- 4x precise volume controls.
- 6 LED indicators per channel.
- Power on/off switch, 19″ rack mount.
Rear Panel Shows:
- Input connectors 4x FXLR sockets.
- Output connectors – 4x Speakon sockets.
- Sensitivity selector switch (41dB, 38dB, 35dB, 32dB), the same switch works as clip on/off switch, it also works as operation mode switch.
- 4x force cooling fans.
| Rated Power (Stereo)* | 2×2000W @2Ω, 2x 1600W @4Ω, 2×1000W @8Ω |
|---|---|
| Rated Power (Bridge) | 1×3200W @4Ω, 1×2400W @8Ω |
| Damping Factor | >800 |
| Smart Protections | DC, Short Circuit, Over Heat, Clip, In/Out Overload |
| Cooling | 2× Force cooling fans |
| Input Sensitivity | 0.775V/1V/1.4V |
| Frequency Response | 15Hz – 25kHz |
| S/N Ratio – Slew Rate | 105dB / 40Vµs |
| Input Connectors | 4× FXLR socket for signal input |
| Power Supply | 220V AC ±10% ~ 50Hz |
| Output Connectors | 2× Speakon NL4 socket |
| Dimensions (MM) | 482x455x132 |
| Weight | 24Kg |
HAX 4000 is designed and tuned for unmatched clarity and performance. The class H circuit provides high efficiency and top notch reliability with Japanese internal parts. The inbuilt crossover has LOW CUT for using line arrays and tops with ease and SUB WOOFER mode for eliminating HF and MF for pure low end performance, with frequency cut off control upto 100Hz.
In built processor boosts low end frequencies for elevated bass performance even in your dual 15″ tops. Intelligent cooling system keeps the temperature maintained even in demanding conditions.
