RTX-1122/1124/1126
Single 12″ Two Way
The RTX (1122, 1124, 1126) is a trapezoidal single 12″ two way speaker system for use in live sound, dance, music, speech reinforcement and portable addressing system. It’s compact size provides outstanding coverage and output coherence, while delivering clarity and flexibility of handling power up to 600 watts. “[B4] Beta Four” 112 Series fitted with high quality 12″ LF speaker and high compression driver and is available in three different models each with distinct characteristics and applications.
| Specification | RTX-1122 | RTX-1124 |
|---|---|---|
| System Typе | Single 12″ Two Way speaker system | Single 12″ Two Way speaker system |
| Power Rating (Continuos) | 350 Watt | 400 Watt |
| Frequency Response | 60Hz-20KHz | 55Hz-20KHz |
| Sensitivity SPL 1W/1M | 96 dB | 99 dB |
| Nominal Impedance | 8Ω | 8Ω |
| Low Freq. Speaker | 1×12″ 200 Watt Speaker, MS Frame, 2″ voice coil 155x60x20(mm) magnet | 1×12″ 350 Watt Speaker, MS Frame, 2.5″ voice coil 160x80x20(mm) magnet |
| High Freq. Unit | 1xHorn 8″x10″ with 60 watt Neodymium HF driver | 1xHorn 8″x12″ with 60 watt HF Driver, Titanlum diaphragm |
| Crossover Protection | Inbuilt for HF Driver | Inbuilt for HF Driver |
| Port | Free Flow Flared | Free Flow Flared |
| Input Connectors | 2x Speakon NL4 | 2x Speakon NL4 |
| Dimensions | Width (Front): 409mm (16″ in) Width (Back): 254mm (10″ in) Height: 584mm (23″ in) Depth: 330mm (13″ in) | Width (Front): 409mm (16″ in) Width (Back): 254mm (10″ in) Height: 584mm (23″ in) Depth: 330mm (13″ in) |
| Weight (Kg) | 16.5 Kg | 18 Kg |
