TD 16K2
Front Panel Shows: Precision-dependent volume controls, Power on/off switch, easy to carry front handles, 19″ standard rack mount design housed in an all-steel 3u chassis.
Rear Panel Shows: Input connectors 2x mXLR & 2x fXLR sockets. Output connectors – 2x Speakon sockets and 2x Binding post terminal for channel A and B. Operating mode switch (stereo/parallel/bridge). In-built crossover with frequency control with upto 200Hz cut off. Fuse holder for AC high voltage protection.
BASS BEAST & BEYOND
| Program Power (Stereo)* | 2x 7500W @2Ω 2x 6000W @4Ω 2x 3750W @8Ω |
|---|---|
| Rated Power (Bridge) | 10000W @4Ω 7500W @8Ω |
| Damping Factor | >3600 |
| Smart Protections | DC, Short Circuit, Over Heat, Clip, In/Out Overload |
| Cooling | 2x Force cooling fans |
| Input Sensitivity | 0.775 / 1 / 1.4V |
| Frequency Response | 20Hz – 20kHz |
| S/N Ratio – Slew Rate | 100dB / 30vUs |
| Input Connectors | 2x FXLR, 2x MXLR socket for signal output |
| Power Supply | 220V AC ±10% ~ 50Hz |
| Output Connectors | 2x Speakon NL4 socket & Binding Posts for speaker output |
| Dimensions (MM) | 555W × 488D × 132H |
| Weight | 40 kg |
The TD-16K2 is a class TD dual channel power amplifier. It has a pure copper premium transformer, with ultra reliable transistors and capacitors. It is crafted to run your high power sub-woofers with ease. It also has 2 intelligent cooling fans for heat dissipation which keeps it cool and running even in the hottest weather across India. It also has protection systems like overheat protection, short circuit protection and output DC protection. With its low THD of 0.05%, clarity is unleashed in every show at its best. The silicon based capacitor tank fulfils all the requirements your subs would demand. Reliability is at its best with TOSHIBA transistors from Japan.
Front Panel Shows:
Precision dependent volume controls, LED indicators for Signal, Clip, Active and Protect. Power on/off switch. Handles with 19″ rack mount. Exclusive panel design.
Rear Panel Shows:
2x MXLR and XLR inputs, 2x Speakon output connectors, binding post terminals for both channels, sensitivity, ground and output mode switches. Crossover sub-full switch with frequency control knob 20–200Hz. 4x force cooling fans.
